(Plateaus-12250)

Brief introduction Parameter Feature Transport Package

Nominal Voltage: 12V

Nominal Capacity: 250AH

Approximate Weight: 69Kgs (152.08Ibs)

Dimensions: 529(20.47)*269(10.59)*220(8.66)*225(8.86) mm/in

Packing Data for 20GP FCL
Qty of battery	Cases/20GP	Total G.W.	Total Volume
342	19	24985	20.41
Battery will be put into carton box, then packed into plywood case. (1pc/Carton, 18pcs/Case)

INQUIRY

Nominal Voltage	12V
Nominal Capacity	10Hr Rate to 10.8V @25℃(77℉) 250Ah
Cycle Use Charging Voltage	14.4V @25℃(77℉)
Terminal	M8-Φ18
Operating Temperature Range	-50℃ to 65℃(-58℉~149℉)
Advice operating temperature	15℃~25℃(59℉~77℉)
Self Discharge @ 25˚C(77˚F)	HUAFU Plateaus series battery self-discharge <3%/month@25℃(77℉),can be stored up to 6 months at 25℃(77℉) and then a freshening charge is required. If the storage temperature higher than 25℃(77℉), a freshening recharge will be required sooner.
Case and cover	A.B.S. (UL94-V0 Optional)
Design Life time	8 Years
