CNJ Series-Waterproof Battery(12V 110Ah [IP67])

Brief introduction Parameter Feature Transport Package
12V
110AH
31.5Kgs (69.43Ibs)
406(15.98)*174(6.85)*208(8.19)*232(9.13) mm/in
Packing Data for 20GP FCL
Qty of battery Cases/20GP Total G.W. Total Volume
690 23 25231 19.63
Battery will be put into carton box, then packed into plywood case. (1pc/Carton, 30pcs/Case)
INQUIRY
Nominal Voltage 12V
Nominal Capacity 10Hr Rate to 10.8V @25℃(77℉) 110Ah
Cycle Use Charging Voltage 14.4V @25℃(77℉)
Terminal M8-Φ18
Operating Temperature Range -35℃ to 60℃(-31℉~140℉)
Advice operating temperature 15℃~25℃(59℉~77℉)
Self Discharge @ 25˚C(77˚F) HUAFU CNJ series deep cycle gel battery self-discharge <3%/month@25℃(77℉),can be stored up to 6 months at 25℃(77℉) and then a freshening charge is required. If the storage temperature higher than 25℃(77℉), a freshening recharge will be required sooner.
Case and cover A.B.S. (UL94-V0 Optional)
Design Life time 12 Years
